Product Features

• Large Capacity & Strong Expandability: Equipped with 8 E1 interfaces, expandable from 8 lines to 256 lines (total capacity of multi-service boards such as IPS/IPO/FXS/FXO).
• Powerful Functions: Supports cascading without sub-control boards; adopts an ARM control core for better centralized management of various service boards.
• Unlimited Dispatch Console Access: Dual-loop functionality effectively enhances the reliability of the communication system, ensuring communication security.
• Robust Networking Capabilities: Provides interfaces for E1, loop trunks, E/M trunks, carrier trunks, magneto trunks, and SIP trunks, with tandem functionality supported.
• Integrated Linkage: Enables linkage with multiple systems including video, voice, broadcasting, radio, and distress alarm systems.
• Unit Board Fault Detection & Isolation: Automatically detects and isolates faulty unit boards.
• Group Networking & Multi-Level Scheduling: Supports group networking, multi-level networking, and multi-level dispatch management.
• Centralized Network Management: Service boards such as MCU, REC, and IPS can be connected to the network via RJ45 cables, allowing remote management through WEB or client terminals.
• Built-in Full-Channel Recording: Integrates full-channel recording functionality.
• Modular Design: Allows flexible configuration of total capacity based on customer needs, with hot-swappable support for all boards.
• IPO Board Versatility: In addition to trunk functions, the IPO board supports IP phone registration.
• Long-Distance Terminal Access: Long-distance user boards can connect terminals up to 10KM away.
• Redundant Backup: MCU main control board, recording module, primary power box, and secondary power supply all support dual redundancy backup.
• Environmental Resistance: Equipped with lightning protection, overcurrent/overvoltage protection, and three-level lightning protection measures to ensure stable operation in harsh environments.

System Advantages

• Open Architecture & Independent Control: Adopts the standard SIP protocol with a digitally open architecture for flexible expansion and independent control.
• Flexible Deployment: Based on IP network architecture, supports cross-network and cross-router deployment (LAN or Internet) via wired or wireless IP networks.
• High Integration, Centralized Control & Efficient Collaboration: Integrates functional modules such as voice communication, broadcasting, integrated administrative and dispatch functions, and recording.
• Customizable Interfaces & Flexible Expansion: Provides an open SDK for future development of new business functions and integration with third-party platforms.
• Powerful Dispatch Integration: Kangyou Kaixin converged communication dispatch system integrates TDM architecture with IP networks, offering an all-in-one solution for multimedia dispatch services (voice dispatch, video linkage dispatch, conference calls, SMS notifications, broadcast notifications, trunked intercom dispatch, gas alarm linkage, etc.). It supports integration with third-party data services, security alarms, emergency plans, and GIS systems to form a robust multimedia communication platform.

Key Dispatch Functions

• Voice Dispatch: Enables dispatch of analog/IP phones, mobile phones, walkie-talkies, etc., via the dispatch console, with functions including individual call, group call, sequential call, conference call, intrusion, disconnection, auto-answer, monitoring, muting, transfer, roll call, and call pickup.
• Video Dispatch: One-click dispatch allows binding IP/analog cameras with communication terminals (landlines, mobile phones). When the console calls a terminal, the system displays the corresponding monitoring video, realizing integrated audio-visual command and dispatch.
• Broadcast Dispatch: Supports voice notifications, public broadcasting, voice 喊话，TTS text-to-speech broadcasting, priority broadcasting, command broadcasting, scheduled broadcasting, and task-based broadcasting. Emergency broadcasting can be triggered manually (or automatically) during emergencies, with video linkage support. Custom scheduled broadcasting plans (time, region, content) can be preset. Leaders/dispatchers can broadcast via landlines, mobile phones, or consoles, with support for multiple simultaneous audio sources and microphones.
• SMS Dispatch: Dispatchers can manually send SMS to mobile terminals via the console. In emergencies, the system automatically sends individual/group SMS according to preset plans.
• Trunked Dispatch: Supports hybrid wired/wireless intercom networking, enabling communication between landlines, mobile phones, and walkie-talkies (dial-up or one-click call). Compatible with various walkie-talkie models and standards; supports walkie-talkie-triggered broadcast.
• Alarm Dispatch: When danger is detected, the alarm system automatically sends signals to the command platform (or manual one-click alarm), triggering audio-visual alerts on the console and automatic danger broadcasts in relevant areas.
• Plan Dispatch: Upon receiving help/fire alarms, preset plans are activated (e.g., auto-calling relevant personnel/leaders, sending reminder SMS, playing emergency broadcasts).
• GIS Integration: Uses GIS for location tracking of terminals. The console enables one-click calls to terminal locations and displays bound monitoring videos.
• Integrated Administrative & Dispatch Functions: Supports unified and hierarchical dispatch, covering daily office communication, production dispatch, emergency dispatch, and monitoring of communication terminals.
• Standard IP Networking: Internally, IP-compatible devices/terminals can be deployed anywhere with IP/wireless coverage. Externally, it connects to IMS platforms via IP or to remote communication devices via IPO, supporting centralized/distributed deployment.
• Zone Management: Terminals can be categorized by region for flexible management and dynamic adjustments.

Board Types

• Special Function Boards: REC recording board, HF trunked gateway board, AUD audio interface board, DMB broadcast system board, ALM dry contact alarm board, RLD converged linkage board, etc.
• Trunk Boards: FXO loop trunk board, IPO trunk board, PCM digital trunk board, E/M trunk board, carrier trunk board, magneto trunk board, etc.
• User Boards: FXS analog user board, IPS user board, LFXS long-distance user board, QFXS group call user board, AFXS long-distance group call user board, etc.

Additional Features

• Teleconferencing: Supports ad-hoc and fixed-group conferences, with participation from internal/external IP phones, landlines, walkie-talkies, and mobile phones. Up to 128 participants per conference (64+ full-duplex speakers); one-click conference initiation via the console.
• Monitoring & Recording: Real-time monitoring and high-performance recording boards support recording of all communications (calls, conferences, tandems). Recordings can be queried, played, or downloaded via software or WEB.
• Diverse Terminal Access: Compatible with dispatch consoles, analog/SIP/magneto phones, WIFI mobile phones, IP/analog cameras, microphones, headsets, analog/network amplifiers, network speakers, loudspeakers, explosion-proof phones, walkie-talkies, SOS alarms, and access control systems.
